Automatic Infrared Gate Sensor

Swing & Sliding Gate Object Sensor 20M

Exclusive for Lockmaster automated gate hardware, these infrared sensor are the ones to go for keeping your automated gate safe. These photocells will insure that your automatic gate will not close on someone or something. Have the peace of mind knowing your family and vehicle will be protected from the occasional mishap that can happen sometimes.

Features
* Hard frosted photocell
* Design for any rough weather
* Infrared technology
* Detection range up to 20M
* Automatic beam for detection
* 12 months warranty
* Technology: Infrared (Photocell)
* Receiver range: ≤20m. Range can be reduced to 30% in bad weather conditions.
* Frequency: 1.92Khz
* Power supply: 12-24 DC/AC
* Wave length: 940mm
* Input: RX 15mA-TX 30mA, Angle: ＜± 10°
* Working temperature: -20°C - ＋70°C
* Relay output: 1A max 30V
* Product weight: 0.2kg
* Product dimension: 7.5 x 4.9 x 3cm

Package Contents
2 x Infrared photocell
1 x User Manual
